Technical Details
- Easy-to-use editing machine with a variety of interfaces, compact design, long-time recording ability and a wide range of options for professional studio needs
- Allows you to switch between NTSC or PAL as required, and supports direct playback from DVCAM recordings
- Built-in time code generator with the 20x search function provides super-fast access to any target point on the tape with visible pictures
- Runs on 12 volts of electricity via the included AC adapter
- Weighs approximately 9.9 pounds, and measures 8.375 x 3.5 x 12.875 inches (W x H x D)
Product Description
Designed specifically to function within a non-linear editing system, the BR-DV6000U(B) is an ideal spooler and flexible, easy-to-use editing machine with a variety of interfaces. Compact design, long-time recording ability and a wide range of options including network board, make the BR-DV6000U(B) the right choice for professional studio needs.
Amazon.com Product Description
Designed specifically to function within a non-linear editing system, the JVC BR-DV6000U(B) Advanced Professional DV Recorder is an ideal spooler and flexible, easy-to-use editing machine with a variety of interfaces. Compact design, long-time recording ability and a wide range of options including network board make the BR-DV6000U(B) the ideal choice for professional studio needs.
The JVC BR-DV6000U(B) allows you to switch between NTSC or PAL as required, so it easy to work with internationally sourced material and transfer it to a non-linear system for editing. You can also record to Standard or Mini DV tape in either NTSC or PAL formats, though this DV recorder cannot be used as an NTSC/PAL converter. DVCAM recordings can also be played back directly on the BR-DV6000U(B), making it easy to use DVCAM recordings as source material for editing. This unit includes a built-in time code generator that provides preset (rec run) and regene time codes, which in combination with the 20x search function (100x max in the FF or REW mode) provides super-fast access to any target point on the tape with visible pictures. The BR-DV6000U(B) features an indicator light showing when audio signals are input as a convenient way of checking for the presence of audio signals during tape playback, as well as a continuous recording function that will start recording five minutes before the tape in a camcorder (connected via the DV connector) ends, which enables continuous shooting for extended periods with no breaks in the recording. This system also features repeat playback, so when the video signal ends or tape ends, playback starts again from the beginning of the recorded video or tape. And all of these features and functions are enhanced by the high-resolution 2.5-inch color LCD display on the front panel, which provides monitoring and editing convenience, video viewing, plus data including time code, audio level meter, menu setting, and mode are shown.
This DV recorder not only has expanded compatibility with the latest professional editing systems, but includes a Digital Automatic Error Correction (DAEC) circuit that allows it to playback all kinds of DV and DVCAM tapes, even those that are out of spec due to worn heads or misaligned camcorders. Systematic, easy-to-understand menu screens simplify setting and operation procedures, while a remote connector lets you connect the optional RM-G30 controller to run the entire system from a distance, including in a daisy-chain fashion with several machines. The BR-DV6000U(B) DV recorder and player features an optional SA-X65U card that provides SDI output including two-channel embedded audio and a separate AES/EBU output, and an optional RS-232C interface (SA-K46U) that can be used to connect it directly to a PC for computer-controlled operation. This provides connectivity to a wide range of broadcast and professional editing systems that use uncompressed digital signals. The BR-DV6000U(B) is equipped with an industry standard DV (IEEE1394 or Firewire) connection that allows recordings to be transferred to and from a wide variety of other digital systems, including popular non-linear editing systems. Dubbing can be performed with another DV deck or camcorder with no loss in audio or video fidelity. In addition to DV input/output, the BR-DV6000U(B) is equipped with a Y/C (S-video), and component input/output and composite (RCA) input/outputs that let it serve as a digital/analog interface for legacy analog devices like an S-VHS or Betacam recorder, as well as including an industry-standard RS-422 interface that allows for connection to a wide range of external components. There is even a wireless remote control that provides control over field advance, frame advance, menu display, audio reference-level selection, color bar display and blank search, as well as basic operations.
JVC's BR-DV6000U(B) is built with a heavy-duty, full-size mini-DV multi-motor mechanism for fast and reliable NLE spooling and editing, and includes locked audio, continuous backup recording, and variable noiseless slow motion at plus or minus 33-percent. This unit also allows audio dubbing via a microphone connector, contact closure recording, variable speed search, time-code reading and generation, and 7.5 IRE setup (on/off). This DV recorder runs on 12-volts of electricity via the included AC adapter, has a horizontal resolution of 500 lines or more, weighs approximately 9.9 pounds, and measures 8.375 x 3.5 x 12.875 inches (W x H x D). Compatible with standard mini-DV tapes, this unit allows up to 276 minutes of record and play time.
What's in the Box
BR-DV6000U(B) DV recorder, AC adapter and cable and user's manual.
